Floor, Wall or Roof Cut Aways.

[Keystone]

Does anyone have a floor, wall and roof cut away / sectional view that is unlabeled and would be willing to share???
Prefer separate but I’ll gladly accept what is offered.



[north star]

% ~ % ~ %

Not sure this is what you're looking for.

The Link: https://mtcopeland.com/blog/what-is-a-sectional-view-6-types-of-sectional-views/





You might reach out to Mark Handler to see if he has anything.

% ~ % ~ %



[Keystone]

I’m seeking a floor, wall and or roof section that is a side side or front profile which shows unlabeled segments.
Example, wall sheathing, studs, top and bottom plates and window/door opening with header.



[Paul Sweet]

Sections are usually drawn to verify that everything works out in the third dimension, so they are usually unique to the project.

Some building inspection departments have blank sections where you can fill in dimensions & framing sizes to go along with the plan that was submitted on a napkin. These are often incomplete, lacking such minor items such as flashing, waterproofing, etc.



[Keystone]

Sections are usually drawn to verify that everything works out in the third dimension, so they are usually unique to the project.

Some building inspection departments have blank sections where you can fill in dimensions & framing sizes to go along with the plan that was submitted on a napkin. These are often incomplete, lacking such minor items such as flashing, waterproofing, etc.

That sounds exactly what I was inquiring about, I’m looking for something like that, simple.
It’s for a personal pet project.



[bill1952]

Have you tried googling for "floor cut away diagram" for instance? There are lots. Here's one:



[mtlogcabin]

Scroll to the bottom of the page to Helpful Documents, they are very basic and about 20 years old.
Also the Detached Garage section has examples in there also.

Permit Applications and Design Criteria | Kalispell, MT

View the various permits you can apply for in the City of Kalispell.

www.kalispell.com
